10 Inch Mining Rubber Lined Slurry Pump With Hi Chrome Impeller Shr/250st

10-inch Rubber Lined Mining Slurry Pump Heavy Duty Centrifugal Type with Hi-Chrome Impeller SHR/250ST

Introduction:

Slurry pumps are designed and engineered for the most rugged and demanding installations. For years, our slurry pumps have exceeded operating expectations, and provide hydraulic fracturing companies unprecedented uptime, reliability, and efficiency.

SHR/250ST (12/10ST-R) is a very popular model among horizontal slurry pump selections. It is a horizontal pump that is used on the surface and connected with discharge pipes to move sludge, slag, and silt from one tank to another. They are suitable to handle very abrasive and erosive slurries.

1) Simple structure in liner type, easy in installation and maintenance.

2) Adopting advanced world famous brand components in pneumatic parts, electric parts, and operation parts.

3) High-pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization, no pollution.

5) Apply a linker to connect with the air conveyor, which can directly inline with the filling machine.

Specifications:

Model	SHR/250ST
Inlet	12-inch
Outlet	10-inch
Capacity	500~2000m3/h
TDH	10~45m
Rated Motor Power	560Kw
Speed	300~650/min
Max. Eff.	80%
NPSH	2~8m

Type	Size	Frame	Impeller:G10147A05	Shaft Seal Type	Frame Rating(KW)	Normal Max Speed(r/min)	Passage Size(mm)
SHR	250	ST	5 Closed Metal Vanes, Diameter: 762 mm	Gland Packing, Expeller, Mechanical Seal	560	650	86

Typical Applications:

Ash Handling
Cyclone Feeds
Pulp and Paper
Abrasive Slurries
Coal Preparation
Mineral Processing
Aggregate Processing

Mineral Processing
Tailing Delivery
Diamond Concentrate
Slag Granulation
Mill Discharge
Chemical Processing
Coal Preparation
Effluent Handling

Chemical Process
Sand and Gravel
Heavy Minerals
Lime
Green and White Liquor
Mill Discharge
Bottom Boiler
Fly Ash
Cyclone Feed
Abrasive Dewatering

Material: High Chrome Alloy A05

Material Chemical Requirements, Weight%

Description

Material Name

Description

Hardness

A05

Ultrachrome

2.92

0.98

0.54

0.8

≤0.8

...

0.062

...

0.051

27% Cr Erosion Resistant White Iron

58-62HRC

Performance Curve:

Similar Products(Replacement of Warman Centrifugal Slurry Pumps):
